Product Advantage
1. Premium Material and Advanced Welding Technology
Manufactured from high-energy Q235 carbon steel, the product ensures a sturdy and durable structure with excellent tensile strength and toughness. It is designed to withstand high loads and frequent tilting operations, thereby extending equipment lifespan. Precision seam welding services, uniform and sturdy.
2. Precision Machining with Horizontal Machining Center
Key mating surfaces are processed with a horizontal machining center to achieve strict dimensional tolerance control, ensuring smooth cylinder tilting action, reliable sealing, and enhanced overall equipment performance.
3. Optimized Structural Design with Multiple Custom Specifications
The compact and well-engineered design meets the tilting requirements of industrial equipment, improving the positioning accuracy of welded workpieces and supporting efficient automated production. Custom sizes and load capacities are available to fit various industrial welding and assembly systems.
4. High-Quality Wear Resistance
With surface treatments and precise machining, the product offers excellent wear resistance and corrosion protection, adapting to complex working environments and ensuring long-term stable operation.
Technical Parameters
| Product Parameters | Content |
| Product Name | Gearbox Welding Turnover Cylinder |
| Application | Construction Machinery / Shipbuilding Industry |
| Material | Q235 |
| Surface Treatment | Powder Coating / Spray Painting |
| Weight | 20-100KG |
| Tolerance Class | IT:7 |
| Minimum Order Quantity | ≥5EA |
| Surface Roughness | RA:1.6-12.5 |
| Processing Technology | Stamping / Bending / Sheet Metal / CNC Machining / Welding / Spray Painting |
| Production Volume | Over 30 Pieces Per Month |
| Heat Treatment | Normalizing and Stress Relief Annealing |
| Hardness | HB300 |
Product Uses
1. Automotive Manufacturing and Welding Line Processes
Welded tilting cylinders are widely used for multi-angle welding operations on components such as vehicle frames, chassis, and suspension systems. By automatically rotating the workpiece, they enable precise positioning and rapid adjustment, improving welding efficiency while ensuring weld consistency and structural strength.
2. Construction Machinery and Heavy Equipment Structural Parts Manufacturing
In the processing of structural parts for large machinery such as excavators, loaders, and cranes, tilting cylinders provide stable rotation and positioning of heavy steel components. Their superior load capacity and stability make them ideal for high-load, high-intensity continuous welding operations.
3. Shipbuilding and Large Steel Structure Engineering
Used for welding and tilting large structural components like ship hull sections, decks, and keels, these cylinders work in conjunction with gantry welding machines or robotic arms. They support multi-angle, long-duration operations, meeting the flexibility requirements for space and angles during large workpiece welding, thereby enhancing weld quality and construction efficiency.
Product Operate Guide
Before use, ensure all connection points of the equipment are securely fastened, and the cylinder moves smoothly without any sticking. When installing the workpiece, adjust the clamping points according to its center of gravity to guarantee stable and safe tilting.Prior to operation, check that the hydraulic system pressure is normal and confirm that the control system responds accurately. During use, strictly avoid overloading or sudden start-stop actions to prevent damage to the cylinder body and mechanisms.After welding, promptly clean off any surface slag and regularly inspect wear-prone parts such as oil seals and pins to ensure long-term stable operation of the equipment.
Product Video
FAQ
1. Q: What workpieces or industries are welded tilting cylinders mainly used for?
A: They are primarily used for tilting and positioning large structural components in industries such as automotive, construction machinery, shipbuilding, and pressure vessels. They are suitable for multi-angle processing and assembly of long or heavy welded workpieces.
2. Q: Can the product be customized according to customer requirements?
A: Yes. We support OEM customization based on customer drawings. Tilting angles, load capacities, mounting methods, and other specifications can be tailored to meet specific operating conditions.
3. Q: What material is the tilting cylinder made of? Is there any heat treatment?
A: The tilting cylinder is made of Q235 carbon steel. After welding, it undergoes annealing treatment to relieve internal stresses and prevent structural deformation and fatigue cracking during use.
