Product Advantage
1. Excellent Pressure Resistance
Manufactured from high-strength materials and treated with advanced heat processing techniques, the tee fitting ensures long-term, stable operation under high-pressure conditions, effectively preventing leakage and rupture.
2. Outstanding Corrosion Resistance
The surface is treated with specialized anti-corrosion coatings, making the product highly resistant to oil, natural gas, and various chemical media. This ensures reliable performance even in harsh and corrosive working environments, significantly extending service life.
3. Precision Dimensions & Standardized Connections
Produced in strict accordance with API, ASME, and other international or industry standards, ensuring seamless compatibility with pipeline systems. Enables fast, secure installation and easy maintenance.
4. High Sealing Efficiency & Durability
Incorporates advanced sealing design and precision machining to ensure tight, leak-proof connections. The optimized structure enhances mechanical strength and impact resistance, making it ideal for frequent startups, shutdowns, and vibration-prone conditions in the oil and gas sector.
5. Versatile Specifications & Customization Options
Available in various diameters, angles, and connection types to suit different pipeline configurations. Custom solutions can be provided based on specific project requirements, ensuring flexible adaptation to diverse working conditions.
Technical Parameters
| Product Parameters | Content |
| Product Name | Tee Fitting |
| Application | Pipeline Industry |
| Material | HT250/304/316 |
| Surface Treatment | Painting |
| Weight | 200-5000KG |
| Tolerance Class | IT:8-10 |
| Minimum Order Quantity | ≥5EA |
| Surface Roughness | RA:1.6-12.5 |
| Processing Technology | CNC |
| Production Volume | Over 200 Pieces Per Month |
| Casting Method | Sand Casting |
| Heat Treatment | Stress Relief Annealing |
| Hardness | HB240/HRC32 |
| Testing Method | CMM |
Product Uses
1. Oil and Gas Transmission Pipeline Systems
Tee fittings are widely used in crude oil and natural gas trunk pipelines to enable fluid diversion, merging, or directional change. Designed to withstand high pressure, high temperature, and corrosive media, they ensure stable pipeline operation under harsh and complex working conditions.
2. Refinery Process Pipelines
In various stages of refinery operations, tee fittings serve as key components connecting different process units. They enable efficient transfer and switching of media between units. Their precise fluid control capabilities help optimize process flow, enhance product conversion rates, and improve overall operational efficiency.
3. Chemical Plant Piping Connections
As essential pipeline junctions, tee fittings are suitable for transporting a variety of specialized media. With excellent sealing performance and media compatibility, they meet the demands of complex and variable processes, ensuring both operational safety and accurate medium delivery.
Product Operate Guide
Before installation, verify the tee fitting’s model, size, and material match the pipeline system. Check for cracks, corrosion, or deformation, and ensure sealing surfaces are clean. Choose welded, threaded, or flanged connection as needed. Avoid external force during installation and ensure correct orientation. After installation, conduct pressure and leak tests before operation. Perform regular inspections to maintain long-term reliability.
Product Video
FAQ
Q: What connection types do your tees support?
A: Our tees support multiple connection methods, including butt weld, socket weld, threaded, and flange connections, customizable to meet specific pipeline system requirements.
Q: What media are the tees suitable for?
A: Our tees are widely used for transporting oil, natural gas, steam, water, chemical fluids, etc. Material selection is based on the corrosiveness and temperature of the medium.
Q: Can tees be customized for special working conditions?
A: Yes, we offer OEM/ODM customization, including special diameters, thicker walls, non-standard angles, and materials such as stainless steel, carbon steel, and alloy steel to meet various complex requirements.
Q: Do your products comply with industry standards?
A: All tees are manufactured strictly according to ANSI/ASME, DIN, GB, and other international or domestic standards, support third-party inspection, and provide material and factory inspection reports.
