1.High-Precision 5-Axis CNC Machining with Ultra-Tight Tolerance Control
Our motor rotor support is manufactured by professional 5-axis CNC machining, achieving an overall dimensional tolerance of ±0.02 mm and a bolt hole position accuracy of 0.03 mm. The high-precision process ensures the rotor assembly coaxiality ≤0.05 mm, meeting the strict assembly requirements of large motors and completely eliminating assembly gaps caused by machining errors.
2. Customized Machining Design for Multi-Industrial Scenarios
We support customized design of diameters from 3.2m to 7.8m and exclusive structures according to customer motor parameters, with personalized adjustment of rib layout and welding positions available. The industrial-grade machining process is perfectly adapted to various application scenarios of heavy-duty industrial motors such as wind power and hydropower, meeting all customized production needs.
3. Integrated Machining & Heat Treatment for Enhanced Structural Performance
The product adopts an integrated CNC rough and finish machining process, combined with overall normalizing and tempering heat treatment to ensure uniform material stress distribution. The surface hardness after machining reaches HB220-250 with a yield strength of ≥550 MPa, and its structural strength and durability are far superior to rotor components processed by a single process.
4. High-Precision Segmented Structure for Easy & Efficient Assembly
The splicing surfaces of the segmented support are precision-machined with a flatness error ≤0.01 mm/m. Matched with CNC-machined positioning pins and bolt holes, it enables fast and accurate splicing, reducing on-site assembly time by 40% compared with traditional machined products and greatly improving the assembly efficiency of large motor rotor systems.
5. Professional Surface Machining Treatment for Corrosion & Fatigue Resistance
After precision machining, the product is additionally treated with shot peening and electrostatic spraying, with the machined surface roughness controlled at Ra1.6-Ra3.2. This treatment increases the fatigue strength of the workpiece by 32% and achieves IP65 corrosion protection, ensuring stable operation in harsh industrial environments for more than 25 years.
| Product Parameters | Content |
| Product Name | Rotor Support |
| Application | Wind Power Generators, Hydroelectric Generators, Large Industrial Motors |
| Material | Q355B / 42CrMo Steel |
| Surface Treatment | Shot Peening + Electrostatic Spraying |
| Weight | 800kg - 12000kg (customizable by size) |
| Tolerance Class | ±0.01 mm (Custom Tolerances Available) |
| Minimum Order Quantity | 1 piece |
| Surface Roughness | Ra1.6-3.2 |
| Processing Technology | 5-Axis CNC Machining, Segmented Welding, Integrated Rough/Finish Machining |
| Production Volume | Prototype To Mass Production |
| Heat Treatment | Quenching and Tempering |
| Hardness | HB220 - HB250 |
| Testing Method | Dimensional Inspection, Ultrasonic Flaw Detection, Hardness Testing |
1. Wind Power Generation Field
Suitable for various onshore and offshore large-scale wind turbines, it serves as the core rotor support component, carrying magnetic steel, magnetic poles, etc. It resists high-speed rotational centrifugal force and complex environmental vibrations, enabling stable operation for over 25 years under extreme temperature and humidity conditions of -40℃~60℃.
2. Hydropower Generation Field
Applicable to hydropower station units of different capacities, it adapts to rotor diameter requirements of multiple specifications. High-precision machining ensures efficient transmission of water turbine rotational power, withstanding water flow impact and long-term wet environments to meet the high reliability and low maintenance requirements of hydropower equipment.
3. Industrial Heavy-Duty Motor Field
Widely used in high-voltage motors and asynchronous motors in metallurgy, mining, chemical, building materials and other industries, it provides stable support for rotors. It adapts to continuous heavy-load working conditions, offsets vibration interference in industrial sites, and ensures uninterrupted operation of production equipment.
4. New Energy Supporting Field
Fits emerging scenarios such as energy storage power stations, new energy vehicle drive motors, and photovoltaic supporting motors. It supports customized size and structural design, balancing lightweight and high-strength performance to meet the core needs of new energy equipment for high efficiency and miniaturization.
1.Q: What is the service life of the motor rotor support?
A: Its designed service life is over 25 years under normal working conditions. With regular inspection and maintenance like bolt tightness check, it can match the whole life cycle of large motors and generators.
2.Q: Can the product be customized according to actual requirements?
A: Yes, full customization is supported. We can tailor the diameter (3.2m-7.8m), structural design and processing parameters based on your motor model, working conditions and installation requirements.
3.Q: What are the key maintenance points of the rotor support?
A: Regularly check the bolt tightness and surface anti-corrosion layer, clean up dust and impurities in time. Monitor vibration and temperature during operation, and conduct ultrasonic flaw detection every 3-5 years.
4.Q: What materials are used for the product and why?
A: It is made of low-alloy high-strength steel such as Q355B/Q460C. The material has high yield strength and good weldability, which can withstand huge centrifugal force and vibration, and adapt to various harsh industrial environments.
5.Q: How to ensure the installation accuracy of the rotor support?
A: It adopts high-precision positioning pins and bolt holes with tight tolerance, and is equipped with professional installation drawings. Align the positioning points and fasten bolts evenly according to the specified torque to ensure assembly accuracy.
