Product Advantage
1. High-rigidity Integral Structure
Made from premium HT250 cast iron or high-strength welded steel, ensuring excellent resistance to deformation and long-term stability under heavy loads.
2. Precision Machining Ensures Cutting Accuracy
Finished with full-process machining on a five-axis CNC center, effectively guaranteeing geometric accuracy and parallelism across all parts, enhancing overall cutting precision.
3. Compatible with Various Equipment Models
Customizable according to customer drawings to fit main frames for multi-wire cutting machines, diamond wire cutters, quartz wafer cutting equipment, and other models, meeting diverse platform compatibility requirements.
4. Excellent Surface Treatment and Corrosion Resistance
Surface treatments such as sandblasting, painting, or electrophoresis can be applied as needed to enhance corrosion resistance, adapting to the complex environment of photovoltaic manufacturing, including dust and cooling fluids.
5. Easy Installation with Modular Support
Frame design supports modular assembly and quick positioning, facilitating equipment assembly, transportation, and maintenance, thereby improving overall assembly efficiency.
Technical Parameters
| Product Parameters | Content |
| Product Name | Machine Frame |
| Application | Photovoltaic Industry |
| Material | GB/QT450 |
| Surface Treatment | Painting |
| Weight | 2000-4000KG |
| Tolerance Class | IT:6-10 |
| Minimum Order Quantity | ≥2EA |
| Surface Roughness | RA:0.8-12.5 |
| Processing Technology | CNC |
| Production Volume | Over 40 Pieces Per Month |
| Casting Method | Lost Foam Casting |
| Heat Treatment | Stress Relief Annealing |
| Hardness | HB250 |
| Testing Method | CMM |
Product Uses
1. Multi-wire Silicon Wafer Cutting Equipment
The main frame serves as the core load-bearing structure of multi-wire cutters, supporting multiple cutting wires for efficient, stable, and precise cutting, thereby improving cutting efficiency and yield.
2. Diamond Wire Cutting Machine System
Designed for diamond wire cutting equipment, the main frame provides stable support for the cutting head and guide rails, reducing vibration to ensure cutting quality and surface integrity.
3. Automated Photovoltaic Production Line
In automated silicon wafer production lines, the main frame supports integrated cutting systems, cooperating with robots or automatic feeding devices to achieve continuous, high-precision production.
4. High-load Industrial Environment
Built to withstand complex conditions in photovoltaic manufacturing workshops, such as coolant immersion, dust exposure, and long-term high-intensity operation, ensuring long-term stable performance.
Product Operate Guide
1. Confirm that the main frame’s specifications and model match the cutting machine equipment. Inspect the frame’s surface and mounting areas to ensure they are clean, free of oil and debris.
2. Securely place the main frame on the machine foundation, ensuring full contact with the base surface. Use a spirit level to verify frame levelness. Install guide rails, sliders, and related components step-by-step according to the installation drawings.
3. Perform a no-load running test to confirm there are no abnormal vibrations or noises from the main frame. Check the smoothness of movement for the guide rails and sliders to ensure smooth operation.
4. Regularly clean the main frame and surrounding environment to prevent dust and debris accumulation that may affect precision. Avoid exposure to moisture or corrosive environments for prolonged periods.
